เครื่องTESTER CCTV HD Coaxial Camera 5นิ้ว รองรับ4in1 5Mpx รุ่น5800ACT-VH /PTZ RS485 / VGA HDMI INPUT ราคาถูก
จำหน่ายเครื่องTESTER 4ระบบ AHD TVI CVI 2MP 5Mpx,CCTV ทุกชนิดและกล้อง Analog เดินสายRG6, เทสทดสอบสัญญาณภาพ ราคาถูก,จอ5นิ้ว,รองรับออกจอภาพ VGA HDMI Input ,output TV CVBS ได้,PTZ Support RS485
HD Coaxial Camera Tester 5นิ้ว รองรับ4in1 5Mpx รุ่น5800ACT-VH /PTZ RS485 / VGA HDMI INPUT
The new HD coaxial camera tester is developed for the on-site installation and maintenance of HD coaxial camera, having TVI, AHD and CVI. It also provides many useful functions, such as video display, Control-over-Coax, PTZ control, DC12V output power, audio test, color-bar generator (TV OUT), VGA video signal input, HDMI signal input, RJ45 cable testing, LED lamp etc.
ราคา 3,200 บาท/ชุด
รุ่น : TST0004 (รหัสสินค้า : P01856)
Product Functions
•HD coaxial camera testing
•Control over Coax
•PTZ controller The Tester built-in Pepco-D / P PTZ control protocol, etc., through its own RS485 interface.
•Color-bar generator(TV OUT)
•DC12V 1A output power
Power the camera with DC12V (1A) power output from the tester. It is helpful for testing when the power supply is not available.
•Audio testing
Test the audio input from pickup devices. Connect the tester and pickup device with the audio cable.
•Enhanced network cable testing
By UTP CABLE TEST port on the meter, you can test the connection of network cable.
•VGA/HDMI input (Optional) *
Support VGA/HDMI 1.1 Compliant Digital input, once connecting VGA/HDMI video, please switch selector to select HDMI or VGA mode. The maximum resolution is 1920X1440
•AHD camera test
AHD camera testing, support 1 MP, 2MP, 3MP, 4MP, 5MP.
•TVI camera test (Optional) *
HD TVI Camera testing, support 1MP, 2MP, 3MP, 4MP, 5MP.
•CVI camera test (Optional) *
HD CVI Camera testing, support 1MP, 2MP, 3MP, 4MP.
•LED lamp
It is useful for the engineer to install and maintain security system at night. LED On/Off pressing button, easy to operate.
•The battery graphic display
The tester has advanced power control and protection circuit. Low energy saving, 4 to 5 hours on a single charge. Normally it can be used for 10 hours.
Product Accessories
•HD coaxial camera tester
•Adapter DC5V 1A ( with micro USB cable )
•International Standard 18650 2600ma battery X2
•BNC cable
•RS485 connector
•Power output conversion cable
•Audio cable
•Lanyard
•Tool bag
•Instruction Manual
Operation
•Pressing key more than 3 seconds can turn on the tester.
•If the tester has turned on, pressing key more than 3 seconds can turn off the tester, can also set time off.
•When turn it on, press the key to enter the function menu, press key to quickly switches to the desired function menu.
Video Test
Signal mode : CVBS, HD-AHD, HD-TVI, HD-CVI
Display : 5.0 inch VGA TFT-LCD, 800 ( RGB ) x 480 resolution
Video IN/OUT : 1 channel BNC Input & 1 channel BNC Output
VGA/HDMI Test (Optional) *
VGA/HDMI Input : Support VGA/HDMI 1.0 video input, once connect VGA/HDMI VGA/HDMI
video, please switch selector to select HDMI or VGA mode. The maximum resolution is 1920X1440
Communication : RS485
PTZ Protocol : Compatible with protocols PELCO-D/P
Baud Rate : 1200, 2400, 4800, 9600, 14400bps
Color bar generator : Support standard color bar output (Red, Green, Blue, White,Black, Grey) and testing image output
UTP cable test : Display UTP cable connection status, cable type and the sequence of wires as well as read the number of the test box.
DC12V power output Output : DC12V1A power for camera
Audio input test : 1 channel audio signal input
Power Adapter : DC 5V ( 1.0A)
Battery : Two Built-in 18650 2600mA
Rechargeable : After charging 4-5 hour, working time lasts 10 hours
Operation : OSD menu, select your desired language: English, Chinese,
setting : etc.
Dimension/W eight 170mm x 114mm x 34mm / 400g
